Fuel Tank Truck Series – XINGHUO GROUP

Best Dongfeng 6×4 18000L Fuel Tank Truck – Heavy-Duty, Leak-Proof, Super Reliable for Oil Transport

Aimee Chan — Wed, 18 Mar 2026 07:50:21 +0000

FEATURES

Strong Power Output

6×4 18000L fuel tank truck equipped with 260HP Yuchai Euro 6 engine for heavy-duty oil transport.

Leak-Proof Safety System

6×4 18000L fuel tank truck with European standard tank mouth & subsea valve to prevent oil leakage.

Durable Q235 Steel Tank

6×4 18000L fuel tank truck uses corrosion-resistant carbon steel for long service life.

Efficient Bottom Loading

6×4 18000L fuel tank truck with right-mounted system improves fuel tanker operation efficiency.

Stable Load-Bearing

6×4 18000L fuel tank truck with dual 10-ton rear axles ensures safe heavy oil delivery.

SPECIFICATIONS

6X4 18000L FUEL TANK TRUCK BASIC INFORMATION
Product Model	6×4 18000L Fuel Tank Truck
Overall Dimension	9100×2850×3650 mm
Curb Weight	11300 Kg
GVW	26000 Kg
Front/Rear Overhang	1480/2450 mm
Cab Seating Capacity	2-3 Persons

The above mentioned figures are approximate.

Hot Sale 18 Tons Aluminum Fuel Tank Truck FAW 16m³ 11.2ton Payload 260HP Diesel FL Type Multi-Purpose Tanker for Gasoline Diesel

Leo Li — Tue, 10 Mar 2026 07:23:45 +0000

FEATURES

Lightweight 18-Ton Aluminum Tank

This 18 Tons FAW Aluminum Fuel Tank Truck features a corrosion-resistant aluminum alloy tank reducing overall weight while maximizing 11.2-ton payload capacity. The 16m³ volume accommodates diverse petroleum products with customizable compartment design for multi-product delivery.

Powerful 260HP Diesel Engine

Equipped with FAW self-developed engine, this FAW Aluminum Fuel Tank Truck delivers reliable 260HP power with excellent fuel economy, reducing operating costs while maintaining stable output for mountainous terrain and long-distance routes.

FL Type Multi-Purpose Design

Engineered as an FL-type tanker, this Fuel Tank Truck safely transports both gasoline and diesel. Advanced explosion-proof materials and anti-corrosion tank construction ensure hazardous material compliance with sensitive pressure monitoring systems.

Safety Systems

Sensitive pressure monitoring systems ensuring safe oil transportation
Stable chassis design optimized for liquid load dynamics
Explosion-proof tank construction meeting hazardous material standards
Anti-corrosion protection for long-term durability with petroleum products

Flexible Customization Available

Optional chassis brand for freezer truck: Dongfeng, HOWO, JAC, JMC, FOTON, IVECO, I-SUZU,etc.
Optional Tank Dimensions.
Can be designed as a special vehicle for chemical transportation.

SPECIFICATIONS

Parameter	Details
Vehicle Type	18-Ton FAW Aluminum Fuel Tank Truck
Tank Material	Aluminum Alloy
Tank Capacity	16 m³
Gross Vehicle Weight	18,000 kg (18 Tons)
Payload Capacity	11,200 kg (11.2 Tons)
Engine Power	260HP Diesel

The above mentioned figures are approximate.

Reliable HOWO 15000L Fuel Transport Truck | Carbon Steel Fuel Tanker

Lisa Zhou — Fri, 06 Mar 2026 01:50:04 +0000

FEATURES

Durable and Reliable

The HOWO 15000L Fuel Transport Truck is specially designed for the safe and efficient transportation of gasoline and diesel. Built on a durable HOWO chassis, the fuel tank truck is equipped with a high-strength carbon steel fuel tank with a capacity of 15,000 liters, ensuring strong structural reliability and a long service life for demanding fuel transportation tasks.

Advanced and Safe Structural Design

This HOWO 15000L fuel tanker truck features a professional pipeline layout, a reliable pumping system, and high-quality safety valves to ensure stable and secure fuel transfer during loading, unloading, and transportation. The well-engineered structure improves operational safety and efficiency in fuel distribution operations.

Wide and Practical Application Fields

The HOWO 15000L Fuel Transport Truck is widely used for transporting gasoline, diesel, and other petroleum products. It is an ideal solution for fuel distribution companies, logistics providers, and industrial fuel supply operations that require safe, efficient, and cost-effective fuel delivery.

Powerful and Efficient Transportation Performance

With strong loading capacity and excellent road performance, the HOWO 15000L Fuel Transport Truck is well suited for long-distance fuel transportation. Its robust chassis and efficient mechanical system allow the truck to operate reliably under various road and working conditions.

SPECIFICATIONS

Main Technical Parameters
Dimensions.	8500×2500×3200(mm)	Tank profile size	5720×2150×1500mm
Total mass.	18000 (Kg)	Maximum density of the quasi-transport medium	700 kg/m3
Overall mass.	7800(Kg)	Rated mass.	10005,10070(Kg)
Trailer mass: 1.5 kg	(Kg)	Total tank capacity	15 cubic meters
Approach/Departure Angle:	19/10(°)	Front suspension/rear suspension:	1430/2370(mm)
Number of axes:	2	Top speed:	80(km/h)
Engine parameters
Engine Model.	Engine Manufacturers	Discharge volume (ml)	Power (kw)/horsepower (PS).
WP7H245E62	Weichai Power Co.	6800	180/244
WP7H270E62	Weichai Power Co.	6800	199/270
WP7H300E62	Weichai Power Co.	6800	221/300
MC07.25-61	China National Heavy Duty Truck Group Ltd.	6870	190/258

Heavy Duty 8×4 HOWO 30000L Refueling Tank Truck with Q235 Carbon Steel for Remote Construction

Aimee Chan — Tue, 03 Mar 2026 01:20:43 +0000

FEATURES

Large Capacity & Efficient Transportation

HOWO 30000L refueling tank truck comes with a substantial tank volume of 27.5 cubic meters and an effective volume of 26.1 cubic meters, designed for high-efficiency bulk fuel transportation. It boasts a rated load capacity of 18,335kg or 18,400kg, paired with a total mass of 32,000kg, enabling it to carry large quantities of diesel or gasoline in one trip.

The tank, crafted from Q235 carbon steel with a 5mm head, 4.75mm cylinder, and 4mm partition, ensures durability and safety for hazardous material transport. Equipped with an arc gear oil pump supporting both pumping in and out, along with two European standard tank caps and a subsea valve, it streamlines loading and unloading operations while balancing capacity with maneuverability for various transportation scenarios.

Powerful Performance & Reliable Chassis

Built on the robust HOWO N 8×4 truck chassis, this HOWO 30000L refueling tank truck delivers exceptional performance with a range of high-quality powertrain options. The available engines, including Sinotruk and Weichai models, offer power outputs ranging from 228kW to 341kW, ensuring strong torque and efficient fuel consumption. It features a HW19710 gearbox, MCX16ZG double rear axles with a 4.803 speed ratio, and VGD95 front axles, providing stable handling and load-bearing capacity.

The 11.00R20 18PR tires, double-layer frame, and reinforced multi-leaf springs enhance durability for long-haul operations. With a maximum speed of 80km/h and an advanced EBS 3 system from ZF, it combines performance with reliable braking and stability.

Comprehensive Safety & Practical Configuration

Safety is paramount for this FL-type dangerous goods transport vehicle, equipped with multiple safety features to meet strict standards. The HOWO 30000L refueling tank truck features front disc brakes, a tire blowout emergency protection device for the steering wheel, and air suspension on the rear axle, minimizing accident risk. The side and rear protections made of Q235 steel ensure high visibility and collision resistance. A satellite positioning tachograph enables real-time monitoring, while the exhaust pipe is front-mounted to reduce fire hazards.

Practical additions include a 25-meter hose reel, fuel gauge, refueling gun, two fire extinguishers, and optional direct-power ETC. The HOWO H77L-R cab, fitted with main and auxiliary airbags, MP3, and reverse beepers, offers comfort and convenience for drivers during long shifts.

SPECIFICATIONS

BASIC INFORMATION
Product Model	8×4 HOWO 30000L Refueling Tank Truck
Overall Dimension	11860x2550x3600 mm
Curb Weight	13470 Kg
GVW	32000 Kg
Front/Rear Overhang	1450/2635 mm
Cab Seating Capacity	2-3 Persons
CHASSIS
Chassis Model	HOWO ZZ1326N466GF1K
Pay Load	18335,18400 Kg
Axle Configuration	8×4
Wheel Base	1800+3775+1400 mm
Tire	295/80R22.5
Engine Brand	HOWO/WEICHAI
Max. Speed	80 km/h
UPPER STRUCTURE
Media Type	Fuel Such as Diesel/Gasoline/Engine Oil
Color	Customized
Tank Material	Q235 Carbon Steel
Tank Thickness	4-6 mm (customizable)
ABS	YES
Equipments	Arc Gear Oil Pump (capable of pumping in and out), Single compartment (multiple compartments customizable), Complete bottom loading system (including 1 bottom loading/unloading valve, 1 vapor recovery valve, 1 vapor recovery adapter, 1 set of pneumatic combination switches, 1 overfill prevention probe, and 1 socket), One European standard tank manhole cover, One bottom loading valve / emergency valve, One toolbox, Two hoses, Two fire extinguishers.

The above mentioned figures are approximate.

Dongfeng 9900L Tank Capacity 6600 Kg Payload Industrial Fuel Transport Truck

Lisa Zhou — Sat, 28 Feb 2026 04:01:03 +0000

FEATURES

Large 9900L Tank Capacity for Efficient Fuel Delivery

This 9900L fuel tank truck is designed for high-volume diesel and oil transportation, reducing refill frequency and improving delivery efficiency for industrial and commercial projects.

Reliable Dongfeng Chassis with 6600kg Payload

Built on a durable Dongfeng chassis, this fuel tanker truck offers a strong 6600kg payload capacity, ensuring stable performance for long-distance fuel transport and heavy-duty operations.

Safe & Durable Carbon Steel Tank Structure

The industrial fuel tanker body is manufactured with high-strength carbon steel and professional welding technology, ensuring safe fuel storage and leak-proof operation during diesel delivery.

Export-Ready Configuration for Global Markets

This Dongfeng 9900l fuel tank truck is built to meet international export standards, making it ideal for fuel distribution companies, construction sites, and mining operations worldwide.

SPECIFICATIONS

Main Parameters of Xinghuo CL5122GYY6 Fuel Truck
Dimensions	6840,7150×2200,2400×2800,2900(mm)	Maximum density of the quasi-transport medium	700 kg/m3
Total mass	11950(Kg)	Total tank capacity	9.9 cubic meters
Overall mass	5150(Kg)	Effective volume of tank	9.43 cubic meters
Trailer mass: 1.5 kg	(Kg)	Rated mass.	6605,6670(Kg)
Front passenger	3,2(P)	Anti-lock system:	Yes
Approach/Departure Angle:	24.5/13(°)	Front suspension/rear suspension:	1130/1910,1280/2070(mm)
Axle load:	4360/7590	Wheelbase:	3800,3950,4050,4400(mm)
Number of axes:	2	Top speed:	80(km/h)
Fuel consumption:	21.2,21.2,21.2,21.2,21.2,20.29,19.39,19.07(L/100Km)	Number of spring tabs:	8/10+7,8/8+6
Tire count:	6	Tire specifications:	245/70R19.5 16PR,8.25R20,255/70R22.5 16PR,9R22.5,8.25R20 16PR,9R22.5 14PR
Front wheelbase:	1755,1886,1770,1801(mm)	Rear wheelbase:	1586,1650,1800,1630,1802(mm)
Steering form:	steering wheels	Tank external dimensions	4800×1950×1300(mm)
Engine Parameters
Engine Model	Engine Manufacturers	Discharge volume (ml)	Power (kw)/horsepower (PS).
CY4SK261	Dongfeng Chaoyang Chaochai Power Co.	3856	125/170
D25TCIF1	Kunming Yunnei Power Co.	2499	110/149
D30TCIF1	Kunming Yunnei Power Co.	2977	125/170
D40TCIF1	Kunming Yunnei Power Co.	4052	135/183
YCY30170-60	Guangxi Yuchai Machinery Co.	2970	125/170
Vehicle Fuel Parameters
Fuel type	Diesel Fuel	Criteria	GB17691-2018 National VI
Chassis emission standards	National Six
Reflective Sign Parameters
Marking Company	Changzhou Huarisheng Reflective Material Co.	Trademarks	Luminous, 3M
Marking Model	TM1200-1,983D

HOWO 2000L+2000L Fuel Tank Truck

Aimee Chan — Sat, 28 Feb 2026 02:03:02 +0000

FEATURES

Robust Chassis Configuration

This Sinotruk Howo fuel tank truck is built on the ZZ1047D3414C145 chassis, featuring a classic Dreamcatcher 1880mm single-row cab with a 3360mm wheelbase for stable maneuverability. Powered by the YN4102QBZL engine delivering 116 horsepower, paired with a WLY6TS55C 6-speed manual transmission and reinforced power steering, it ensures reliable performance for urban and rural refueling tasks. Equipped with 7.00R16 14PR vacuum tires, a 4.2t drum rear axle (4.875 speed ratio), and a 120L iron fuel tank, the truck balances load-bearing capacity and fuel efficiency. Additional standard features include clutch booster, spring brake, air dryer, and frame VIN marking, meeting new national standards for safe and compliant operations.

Durable Tanker Body Design

Featuring an upper tanker body constructed with high-quality Q235 carbon steel plates (4.2mm thickness), this 2000L+2000L Fuel Tank Truck ensures exceptional durability and corrosion resistance for long-term fuel transportation. It comes with a pump-in and pump-out system on the right side, integrated with an overflow valve to prevent overfilling risks. Configured with one European-standard tank port and one subsea valve (both on the right), plus two oil delivery hoses and two fire extinguishers, the truck complies with strict safety regulations for flammable liquid handling. A reserved refueling machine position on the left allows flexible customization, while the tank structure is optimized for even weight distribution, enhancing driving stability and reducing rollover risks during transit.

Flexible Customization Options

This refueling truck offers versatile customization to meet diverse customer needs, with optional flow meters, refueling machines, and hose reels available for seamless integration. The absence of factory-installed air conditioning and ABS can be adjusted based on operational environments—air conditioning can be added for hot-climate regions, while ABS can be equipped for enhanced braking safety on slippery roads. The cab’s full-wrap interior and fabric seats provide a comfortable driving experience, and the non-deflector design ensures easy passage through low-clearance areas such as urban tunnels and warehouse entrances. With no mandatory optional equipment, clients can tailor the truck to exact operational requirements, maximizing cost-effectiveness and practicality.

SPECIFICATIONS

BASIC INFORMATION
Product Model	Multiple Compartments Fuel Tank Truck
Overall Dimension	5995x2100x2500 mm
Curb Weight	4495Kg
GVW	2950 Kg
Front/Rear Overhang	1160/1475 mm
Cab Seating Capacity	2-3 Persons
CHASSIS
Chassis Model	HOWO ZZ1047D3414C145
Pay Load	1700 Kg
Axle Configuration	4×2
Wheel Base	3360 mm
Tire	7.00R16 14PR
Engine Brand	Yunnei/Cummins
Max. Speed	80 km/h
UPPER STRUCTURE
Media Type	Fuel Such as Diesel/Gasoline/Engine Oil
Color	Customized
Tank Material	Q235 Carbon Steel
Tank Thickness	4-6 mm (customizable)
ABS	YES
Equipments	Arc Gear Oil Pump (capable of pumping in and out), Single compartment (multiple compartments customizable), Complete bottom loading system (including 1 bottom loading/unloading valve, 1 vapor recovery valve, 1 vapor recovery adapter, 1 set of pneumatic combination switches, 1 overfill prevention probe, and 1 socket), One European standard tank manhole cover, One bottom loading valve / emergency valve, One toolbox, Two hoses, Two fire extinguishers.

The above mentioned figures are approximate.
